Different modifications of minimally invasive osteosynthesis in pilon fractures: comparative study results

Cover Page


Cite item

Full Text

Abstract

Background. Minimally invasive surgical techniques can reduce the degree of surgical injury during osteosynthesis in peri- and intraarticular pilon fractures. However, these techniques do not always achieve anatomical reduction of the articular component and stable fixation of all columns of the distal tibia.

Aim of the study — to test the hypothesis regarding the clinical advantages of multicolumn fixation for comminuted pilon fractures over traditional single-column fixation.

Methods. The study enrolled 55 patients with extra- and intraarticular fractures of the distal tibia and fibula, all of whom underwent minimally invasive osteosynthesis. Patients were divided into two groups based on the number of fixed columns. These groups were comparable in terms of gender and age. The first group consisted of 28 patients who underwent osteosynthesis with one anatomically precontoured plate. The second group consisted of 27 patients who underwent osteosynthesis with two or more plates placed on different tibial columns. The quality of bone fragment reduction was analyzed using control X-rays performed the day after the operation. Functional outcomes were evaluated according to the AOFAS scale at 6 and 12 months post-operation. The incidence of early and delayed complications of osteosynthesis was also determined.

Results. No statistically significant difference was found between the two study groups in terms of quality of reduction (p = 0.23). The median functional outcome score in the first group at 6 months was 63 points [IQR 50.00-73.00] and at 12 months was 74 points [IQR 65.00-83.25]. In the second group, the median scores were 75 points [IQR 67.50-81.00] and 85 points [IQR 71.00-94.50], respectively. Multicolumn fixation of the pilon fracture resulted in statistically significantly higher functional outcome scores at both follow-up periods: at 6 months (p = 0.015) and at 12 months (p = 0.028). The probability of complications in the first group was 4.4 times higher than in the second group: OR = 4.444 (95% CI 1.066-18.528).

Conclusion. Multicolumn fixation of complete periarticular and intraarticular pilon fractures leads to better functional results compared to single-column fixation. It also reduces the risk of complications due to increased stability of the fragment fixation and the resistance of the implant-bone system to physiological stress.

About the authors

Boris A. Maiorov

St. Petersburg I.I. Dzhanelidze Research Institute of Emergency Medicine; St. Petersburg State University; Pavlov First State Medical University of Saint Petersburg

Email: bmayorov@mail.ru
ORCID iD: 0000-0003-1559-1571

Cand. Sci. (Med.)

Россия, St. Petersburg; St. Petersburg; St. Petersburg

Igor G. Belen’kiy

St. Petersburg I.I. Dzhanelidze Research Institute of Emergency Medicine; St. Petersburg State University

Author for correspondence.
Email: belenkiy.trauma@mail.ru
ORCID iD: 0000-0001-9951-5183

Dr. Sci. (Med.)

Россия, St. Petersburg; St. Petersburg

Gennadii D. Sergeev

St. Petersburg I.I. Dzhanelidze Research Institute of Emergency Medicine; St. Petersburg State University

Email: gdsergeev@gmail.com
ORCID iD: 0000-0002-8898-503X

Cand. Sci. (Med.)

Россия, St. Petersburg; St. Petersburg

Kamoliddin K. Gadoev

St. Petersburg State University

Email: dr.kamoliddingk@mail.ru
ORCID iD: 0009-0003-5565-0721
SPIN-code: 6158-2885
Россия, St. Petersburg

Mariya A. Sergeeva

St. Petersburg State University; Pavlov First State Medical University of Saint Petersburg

Email: masharik1990@mail.ru
ORCID iD: 0009-0003-3255-1771
SPIN-code: 1911-1496
Россия, St. Petersburg; St. Petersburg

References

  1. Беленький И.Г., Майоров Б.А., Кочиш А.Ю., Усенов М.Б. Современные взгляды на оперативное лечение пациентов с переломами пилона. Современные проблемы науки и образования. 2018;(4). Режим доступа: https://science-education.ru/ru/article/view?id=27955. Belenkiy I.G., Mayorov B.A., Kochish A.U., Usenov M.B. Modern Views on Surgical Treatment of Pilon Fractures. Modern Problems of Science and Education. 2018;(4). Available from: http://www.science-education.ru/ru/article/view?id=27955. (In Russian).
  2. Canale S.T., Beaty J.H. Campbell’s Operative Orthopaedics. 12th ed. St. Louis, Missouri: Mosby Elsevier; 2013. 4635 p.
  3. Buckley R.E., Moran C.G. Apivatthakakul Th. AO principles of fracture management. 3d ed. Thieme; 2018. 1120 p.
  4. Andalib A., Etemadifar M.R., Rafiee Zadeh A., Moshkdar P. Treatment of Pilon Fractures with Low Profile Plates. Int J Burns Trauma. 2021;11(6):486-493.
  5. Haller J.M., Githens M., Rothberg D., Higgins T., Nork S., Barei D. Risk Factors for Tibial Plafond Nonunion: Medial Column Fixation May Reduce Nonunion Rates. J Orthop Trauma. 2019;33(9):443-449. doi: 10.1097/BOT.0000000000001500.
  6. Viberg B., Kleven S., Hamborg-Petersen E., Skov O. Complications and Functional Outcome After Fixation of Distal Tibia Fractures with Locking Plate – A Multicentre Study. Injury. 2016;47(7):1514-1518. doi: 10.1016/j.injury.2016.04.025.
  7. Penny P., Swords M., Heisler J., Cien A., Sands A., Cole P. Ability of Modern Distal Tibia Plates to Stabilize Comminuted Pilon Fracture Fragments: Is Dual Plate Fixation Necessary? Injury. 2016;47(8):1761-1769. doi: 10.1016/j.injury.2016.05.026.
  8. Chen Z., Chen D., Yang H., Wu W., Dai Z. 360 Degrees Internal Fixation by Double Approaches for High-Energy Closed Pilon Fractures. Zhongguo Xiu Fu Chong Jian Wai Ke Za Zhi. 2015;29(10):1226-1229. (In Chinese).
  9. Lou Z., Wang Z., Liu C., Tang X. Outcomes of tibial Pilon Fracture Fixation Based on Four-Column Theory. Injury. 2023;54(Suppl 2):S36-S42. doi: 10.1016/j.injury.2022.08.017.
  10. Bastias C., Lagos L. New Principles in Pilon Fracture Management: Revisiting Rüedi and Allgöwer Concepts. Foot Ankle Clin. 2020;25(4):505-521. doi: 10.1016/j.fcl.2020.08.004.
  11. Tong G.O., Bavonratanavech S. Tibia and Fibula Distal. In: AO Manual of Fracture Management. Minimally Invasive Plate Osteosynthesis (MIPO), Switzerland: AO Publishing; 2007. Ch. 18. P. 305-325.
  12. Майоров Б.А., Беленький И.Г., Сергеев Г.Д., Гадоев К.К. Малоинвазивный остеосинтез закрытого перелома дистального метаэпифиза большеберцовой кости со смещением отломков. Медикобиологические и социально-психологические проблемы безопасности в чрезвычайных ситуациях. 2023;(30):38-49. doi: 10.25016/2541-7487-2023-0-3-00-35. Maiorov B.A., Belen’kii I.G., Sergeev G.D, Gadoev K.K. Minimally invasive osteosynthesis in displaced closed metaepiphyseal fractures of the distal tibia. Medico-Biological and Socio-Psychological Problems of Safety in Emergency Situations. 2023;(30):38-49. doi: 10.25016/2541-7487-2023-0-3-00-35. (In Russian).
  13. Lakhotia D., Sharma G., Khatri K., Kumar G.N., Sharma V., Farooque K. Minimally Invasive Osteosynthesis of Distal Tibial Fractures Using Anterolateral Locking Plate: Evaluation of Results and Complications. Chin J Traumatol. 2016;19(1):39-44. doi: 10.1016/j.cjtee.2015.07.010.
  14. Майоров Б.А., Беленький И.Г., Кочиш А.Ю., Григорян Ф.С. К вопросу о фиксации малоберцовой кости при ее переломах, сочетающихся с переломами пилона. Современные проблемы науки и образования. 2020;(6). doi: 10.17513/spno.30311. Режим доступа: http://www.science-education.ru/ru/ article/view?id=30311. Mayorov B.A., Belenkiy I.G., Kochish A.Y., Grigoryan F.S. To the Issue of the Fibula Fixation in Cases of Pilon Fractures in Association with Fibula Fractures. Modern Problems of Science and Education. 2020;(6). doi: 10.17513/spno.30311. Available from: http://www.science-education.ru/ru/article/view?id=30311. (Accessed on: 15.04.2024). (In Russian).
  15. Соломин Л.Н., Щепкина Е.А., Кулеш П.Н., Виленский В.А., Корчагин К.Л., Скоморошко П.В. Определение референтных линий и углов длинных трубчатых костей : пособие для врачей. 2-е изд., перераб. и доп. СПб : РНИИТО им. Р.Р. Вредена; 2012. 48 с. Solomin L.N., Shchepkina E.A., Kulesh P.N., Vilenskii V.A., Korchagin K.L., Skomoroshko P.V. Definition of reference lines and angles of long bones. St. Petersburg: RNIITO im. R.R. Vredena; 2012. 48 р. (In Russian).
  16. Ding W., Xu J., Zhu Y., Nian S., Lu Y., Zheng M. et al. Comparative Study on the Clinical Efficacy of Small Plate Assisted Anatomic Plate and Traditional Double Plate in the Treatment of Rüedi and Allgöwer II – III Pilon Fracture. BMC Surg. 2023; 23(1):352. doi: 10.1186/s12893-023-02251-9.
  17. Фомичев В.А., Сорокин Е.П., Коновальчук Н.С., Пашкова Е.А., Середа А.П. Кросс-культурная адаптация и валидация русскоязычной версии шкалы Американской ортопедической ассоциации стопы и голеностопного сустава AOFAS-AHS. Травматология и ортопедия России. 2023;29(4):78-86. doi: 10.17816/2311-2905-16494. Fomichev V.A., Sorokin E.P., Konovalchuk N.S., Pashkova E.A., Sereda A.P. Cross-Cultural Adaptation and Validation of the Russian-Language Version of the American Orthopaedic Foot and Ankle Society Ankle-Hindfoot Scale (AOFAS-AHS). Traumatology and Orthopedics of Russia. 2023;29(4):78-86. (In Russian). doi: 10.17816/2311-2905-16494.
  18. Shafiq B., Zhang B., Zhu D., Gupta D.K., Cubberly M., Stepanyan H. et al. Reducing Complications in Pilon Fracture Surgery: Surgical Time Matters. J Orthop Trauma. 2023;37(10):532-538. doi: 10.1097/BOT.0000000000002637.
  19. Hong C.C., Tan S.H.S., Saha S., Pearce C.J. Fibula fixation in the treatment of tibial pilon fractures - Is it really necessary? Foot Ankle Surg. 2022;28(7):891-897. doi: 10.1016/j.fas.2021.12.007.
  20. Kurylo J.C., Datta N., Iskander K.N., Tornetta P. 3rd. Does the Fibula Need to be Fixed in Complex Pilon Fractures? J Orthop Trauma. 2015;29(9):424-427. doi: 10.1097/BOT.0000000000000304.
  21. Dai C.H., Sun J., Chen K.Q., Zhang H.B. Omnidirectional Internal Fixation by Double Approaches for Treating Rüedi-Allgöwer Type III Pilon Fractures. J Foot Ankle Surg. 2017;56(4):756-761. doi: 10.1053/j.jfas.2017.02.012.
  22. Chen Y., Huang X., Chen Y., Shi C., Li H., Xu J. et al. Comparison of Complications of Early and Delayed Open Reduction and Internal Fixation for Treating Pilon Fracture: A Protocol of Systematic Review and Meta-Analysis. PLoS One. 2021;16(11):e0258962. doi: 10.1371/journal.pone.0258962.
  23. Sommer C., Nork S.E., Graves M., Blauth M., Rudin M., Stoffel K. Quality of Fracture Reduction Assessed by Radiological Parameters and Its Influence on Functional Results in Patients with Pilon Fractures - A Prospective Multicentre Study. Injury. 2017;48(12):2853-2863. doi: 10.1016/j.injury.2017.10.031.
  24. Ketz J., Sanders R. Staged Posterior Tibial Plating for the Treatment of Orthopaedic Trauma Association 43C2 and 43C3 Tibial Pilon Fractures. J Orthop Trauma. 2012;26(6):341-347. doi: 10.1097/BOT.0b013e318225881a.
  25. Kottmeier S.A., Madison R.D., Divaris N. Pilon Fracture: Preventing Complications. J Am Acad Orthop Surg. 2018;26(18):640-651. doi: 10.5435/JAAOS-D-17-00160.
  26. Bakan Ö.M., Vahabi A., Özkayın N. Management of Complex Pilon Fractures: Is It Necessary to Fix All the Columns in AO/OTA Type 43-C Fractures? Injury. 2023;54(12):111153. doi: 10.1016/j.injury.2023.111153.
