Dead or alive — use of indocyanine green angiography for intraoperative assessment of bone vitality in nonunion fractures: a controlled case series of four patients
- Authors: Malagoli E.1,2, Vandenbulcke F.2, Ziadi M.3, Lucchesi G.4, Zini S.5, Kirienko A.1,6
-
Affiliations:
- Humanitas Clinical and Research Center – IRCCS
- Humanitas University
- King Abdullah Medical City
- Ortopediatria Center for Education, Research and Patient Care in Paediatric Orthopedics
- Policlinico San Pietro
- Humanitas University, Department of Biomedical Sciences
- Issue: Vol 30, No 2 (2024)
- Pages: 151-157
- Section: Modern technologies in traumatology and orthopedics
- Submitted: 13.03.2024
- Accepted: 20.05.2024
- Published: 04.07.2024
- URL: https://journal.rniito.org/jour/article/view/17494
- DOI: https://doi.org/10.17816/2311-2905-17494
- ID: 17494
Cite item
Full Text
Abstract
Background. Indocyanine green (ICG) fluorescence imaging is a surgical tool with increasing applications in various surgical disciplines. During nonunion resection, the assessment of bone vascularization is currently based only on the surgeon’s experience. We introduced the use of indocyanine green (ICG) angiography in orthopedics.
The aims of the study: 1) to use ICG fluorescence angiography to evaluate the bone perfusion in patients with atrophic nonunion, where poor or absent ICG flow reveals avascular tissue associated with bone necrosis requiring surgical resections; 2) to describe our case series of patients operated with this technique.
Methods. We used ICG angiography in patients operated for tibial nonunion resection. We administered 0.5 mg/kg of ICG powder dissolved in sterile saline at 2.5 mg/ml concentration. The time from the injection to the beginning of appreciation of the green dye was measured. Non-viable bone was resected accordingly. Patient underwent routine follow-up. We enrolled all the suitable patients operated from April 2019 to June 2021 and matched three control patients for each of them. We reviewed their medical records and noted any relevant data.
Results. We enrolled 4 cases and 12 controls, all male. The mean age was 30.8±6.9 years. The mean duration from trauma to surgery was 10.5 (0.7-25.0) months. The mean duration of surgery was 190.8±40.3 min. The defect size was 4.89±2.03 cm. ICG allowed rapid visualization of bone vascularization after 25-45 sec. No adverse events were observed. The mean external fixation time was 11.8±5.0 months. The mean external fixation index was 2.69±1.10. Seven patients needed a surgical revision during treatment. Three patients underwent reintervention after frame removal. There are no statistically significant differences between cases and controls.
Conclusions. The research findings of this study are limited by the small number of observations. However, this technique is safe, easy, and rapid and may contribute to intraoperative decision of how much to resect. Using ICG could objectively demonstrate bone perfusion to help surgeons to avoid massive bone defects.
Full Text
INTRODUCTION
Neoplastic pathology, congenital deformity, and post-traumatic conditions could result in large bone defects. The management of such bone defects, including maintaining bone length and achieving bone union, remains a challenge to orthopedic surgeons [1, 2, 3]. Many reconstructive techniques are available to reach these objectives. All these procedures include meticulous debridement of all necrotic tissues and stabilization of the skeleton [4, 5]. Assessment of arterial perfusion and venous drainage are important prognostic criteria [6, 7].
Nonetheless, intraoperative assessment is based predominantly on the subjective characteristics, such as tissue color, capillary reperfusion, and the presence of “paprika sign”, a punctuate bleeding from osseous vessels [8, 9, 10, 11]. Therefore, the success of bone defect treatment is strongly dependent on the experience of the operating surgeon. None of these measures have been applied systematically because they are not reliable and repeatable [11].
Fluorescent imaging with indocyanine green (ICG) is a useful technology currently used in several surgical fields, such as reconstructive flap in plastic surgery, colorectal resection and anastomosis, to determine tissue perfusion [12, 13, 14, 15, 16, 17]. ICG binds to plasma lipoproteins and emits a fluorescent signal when excited by near-infrared light, providing anatomic information about organ vascularization and tissue perfusion [12, 13, 18]. The benefits of fluorescent imaging with ICG include high contrast (all tissues are enhanced except for necrotic one), high sensitivity (extremely small concentrations can often be made visible), low cost and ease of use. Furthermore, ICG fluorescence is safe because it is nontoxic and nonionizing, and adverse reactions related to its clinical use are rare; it has a short lifetime in blood circulation allowing repeated applications [5, 13, 19]. During our literature search, we found no documentation of the ICG use in orthopedic trauma [20].
The aims of the study: 1) to use ICG fluorescence angiography to evaluate the bone perfusion in patients with atrophic nonunion, where poor or absent ICG flow reveals avascular tissue associated with bone necrosis requiring surgical resections; 2) to describe our case series of patients operated with this technique.
METHODS
Preoperative assessment
Our preoperative assessment protocol includes:
- interview for a history of iodine allergy or previous anaphylactic reaction to contrast media or dye injection;
- limb examination for neurovascular status and skin condition;
- evaluation of clinical and biochemical evidence of active infection (draining sinus, local inflammation, pain, tenderness, swelling);
- X-ray and CT scan for radiographic assessment of the level and size of bone defect, bone quality, and signs of infection (cavities, sequestrated and sclerotic bone);
- PET/CT or MRI as a second-level investigation to better establish the limits of bone necrosis.
Patients
Due to the explorative nature of this study, it enrolled all the suitable patients from April 2019 to June 2021 and matched three control patients for each of them coupled for age (±5 years), sex, and bone defect size (±3.5 cm). We estimated four patients in the ICG group, a control cohort composed by 12 patients, so the final sample size accounted for 16 patients.
Angiography technique
Among several fluorescent angiography systems available we use Stryker Platform (ENV, Stryker Endoscopy, USA), which has already been available in our institute. The fluorescent dye ICG is intravenously administered, and the tissue in the region of interest is illuminated using near-infrared light at a wavelength of 830 nm; the total output is 80 mW in a field of view of 10 cm in diameter, operating at a distance of approximately 30 cm above the tissue [18]. ICG in powder form (25 mg/vial) is water-soluble and albumin-bound. Its plasma half-life is 3-5 min., and its biliary excretion is completed in 15-20 min. [14]. The blood and ICG suspension under a tissue absorbs the excitation wavelengths and emits a fluorescent band. The emitted light is detected by an infrared-sensitive charge-coupled device camera system through a low-pass filter.
Operative technique
After anesthesia, the patient is placed on the operating table in the supine position. A tourniquet is applied on the upper thigh. The skin incision is made on the nonunion site. Implants are removed where present and tissue samples are obtained for microbiological analysis. The circular external fixator (the Ilizarov frame manufactured by Sintea Plustek s.r.l.) is placed. After the preliminary soft tissue debridement is completed, the tourniquet is deflated. The ICG angiography device is draped and brought into the field. The ICG powder is dissolved in sterile saline at 2.5 mg/ml concentration. The ICG dye solution is injected intravenously as a bolus at a dose of 0.2-0.5 mg/kg body weight (e.g., 8 ml of ICG for a patient weighing 80 kg). The time from the injection and the beginning of an appreciation of the green area is measured. The area of the tissue examined is centered within the screen, including also a tissue with normal perfusion using it as an internal reference.
Observation is made at a distance of 30-50 cm from the tissue of interest. ICG becomes fluorescent once excited by near-infrared light at wavelengths of 830 nm. The fluorescence intensity reaches its maximum within the first 60 sec after injection, and then slowly decreases, depending on the perfusion conditions and hepatic elimination. After resection of necrotic bone, angiography might be repeated waiting approximately 3-5 min. after the initial run to obtain a wash out of the dye from the tissues. If the dye still shows evidence of an avascular bone, further resection is necessary.
After resection, we use bone transport to treat defects >3-5 cm. The osteotomy is performed and the segment is transported gradually (0.25 mm four times per day) to the other side of the defect to regenerate the bone by distraction osteogenesis. In these patients, partial weight-bearing is allowed. To treat bone defects <3-5 cm, we use acute compression at the nonunion level and osteotomy for progressive lengthening (Fig. 1). In these cases, patients are allowed to fully weight-bear immediately. After the procedure is completed, the subcutaneous tissue and skin are sutured, and 2 g of prophylactic cefazolin is administered.
Fig. 1. Nonunion before (а) and after (b) acute compression during surgery
Statistical analysis
Data were described as frequencies and percentages for qualitative variables, or as median, minimum and maximum value (range). Differences between groups were explored using the chi-square test and Fisher correction, for categorical variables, or with the Mann-Whitney U test for continuous variables. P-values lower than 0.05 were considered as statistically significant. All analyses were made with Stata (StataCorp. 2023. Stata Statistical Software: Release 18. College Station, TX: StataCorp LLC).
RESULTS
Cohort description
We enrolled 16 patients undergone bone resection for septic nonunion of the tibia and reconstruction with the Ilizarov method: 4 cases and 12 controls. All surgical procedures were performed by the same surgeon. The mean age was 30.8±6.9 years. All patients were male. The mean duration from trauma to surgery was 10.5 (0.7-25) months. The mean duration of surgery was 190.8±40.3 min. The defect size was 4.89±2.03 cm. The affected bone segment was the proximal tibia in 2 patients (12.50%), the tibial shaft in 9 patients (56.25%) and the distal tibia in 5 patients (31.25%). There are no statistically significant differences between cases and controls (Table 1).
Table 1. Characteristics, outcome and complications of patients undergone bone resection for septic nonunion of the tibia and reconstruction with the Ilizarov method
Parameter | All | Cases | Controls | p |
Number of patients | 16 | 4 | 12 | |
Age, years | 30.8±6.9 | 30.3±6.8 | 31.0±7.2 | 0.789 |
Duration from trauma to surgery, mons | 10.5 (0.7-25) | 18.5 (10-25) | 8.5 (0.7-20) | 0.070 |
Defect size, cm | 4.89±2.02 | 4.50±2.35 | 5.03±2.00 | 0.720 |
District | 0.769 | |||
Proximal tibia | 2 (12.50%) | 0 | 2 (16.67%) | |
Tibial shaft | 9 (56.25%) | 2 (50.00%) | 7 (58.33%) | |
Distal tibia | 5 (31.25%) | 2 (50.00%) | 3 (25.00%) | |
Surgery duration, min | 190.8±40.3 | 185.8±34.5 | 192.4±43.4 | 0.770 |
TEF | 11.8±5.0 | 14.0±6.5 | 11.0±4.5 | 0.578 |
EFI | 2.69±1.10 | 3.25±0.56 | 2.51±1.19 | 0.204 |
Revision | 7 (43.75%) | 2 (50.00%) | 5 (41.67%) | 1.000 |
Re-surgery | 3 (18.75%) | 2 (50.00%) | 1 (8.33%) | 0.136 |
Re-surgery, n | 1 | 3 | ||
Revision or re-surgery, n | 1 (0-3) | 1 (0-2) | 0.5 (0-3) | 0.515 |
*p<0.05. | ||||
Surgical procedure
During the surgery, ICG analysis guided the identification of bone perfusion and supplied information about the surrounding vascular anatomy. In 25-45 sec after the dye solution was injected, the visual effects were observed on the surface of the resecting bone (Fig. 2). ICG fluorescence imaging under near-infrared light was obvious and distinguishable in all patients. In addition, during bone resection, the visual effect of ICG fluorescence continued. We confirmed the bone boundary by observing ICG fluorescence on the cut surface of the resecting side. As indicated in Supplemental Video 1, the appearance of the bone changed from a faint or absent area on the necrotic bone to a clear bright area after debridement and osteotomy. During all procedures, we compared the area of interest with tissues with normal perfusion for use as an internal reference. The ICG angiography was repeated after 10±15 min. to confirm complete resection of necrotic bone (Fig. 3). A minimal residual fluorescence was visible before the new ICG injection that did not negatively affect the image quality of the new ICG angiography.
Fig. 2. Nonunion site before bone resection. Pictures show the normal view (a), lights off (b), and monitor view with lights off and the infrared lamp on (c, d)
Video 1: Non-union site before and after resection of necrotic bone. The video shows the normal view (on the right), lights off (top left), monitor view with lights off (left center), and with the infrared lamp on (lower left)
Видео 1: Место несращения до и после резекции некротизированной кости. На видео показан обычный вид (справа),c выключенным освещением (вверху слева), вид монитора с выключенным освещением (слева в центре) и с включенной инфракрасной лампой (слева внизу)
Fig. 3. Nonunion site after bone resection. Pictures show the normal view (a), lights off (b), and monitor view with lights off with the infrared lamp on (c, d)
Outcomes and complications
The average external fixation time was 11.8±5.0 months. The average external fixation index was 2.69±1.10. After ICG was injected, the oxygen level was reduced due to a bias in the pulse oximeter reading without any clinical relevance. However, no other local or systemic complications were noted during or after surgery. Seven patients needed a surgical revision surgery during external fixation time. Three patients underwent a reintervention after frame removal. There are no statistically significant differences between cases and controls (Table 1).
DISCUSSION
In the treatment of nonunion fractures, surgeons often deal with necrotic tissues resection. Despite technical advances, the surgeons continue to assess bone viability without any instrument. Therefore, the success of the surgical procedures depends on the surgeon’s experience. However, large bone defects may sometimes occur because of the surgeon’s decision to resect the affected bone in a completely subjective manner. In our study, we explored the potential of indocyanine green (ICG) fluorescence angiography as a novel technique for assessing bone perfusion in patients with atrophic nonunion. Our findings show the feasibility and utility of ICG fluorescence imaging in guiding surgical decision-making. ICG fluorescence imaging helps the surgeon to establish limits of resection basing on objective parameters in addition to preoperative planning on PET/CT or MRI. Thus, one can avoid over- or underestimation of tissue to resect.
The same technique is routinely applied in different fields such as colorectal [14], plastic and gynecological surgery [15, 16, 17]. A recent review by S.S. Streeter et al. comprehensively reports current and future applications of fluorescence guidance in orthopedics [21]. Regarding traumatology, an ICG-based dynamic contrast-enhanced fluorescence imaging (DCE-FI) was developed to objectively assess and quantify endosteal and periosteal perfusion in a porcine trauma model [22, 23].
Our results were confirmed by a clinical study on 42 patients with high-energy open fractures. Moreover, ICG-based DCE-FI compared to intraoperative DCE-magnetic resonance imaging (MRI), demonstrated higher sensitivity to perfusion changes, while DCE-MRI provided superior depth-related perfusion information [24]. Furthermore, an automated motion artifact correction approach was developed to reduce motion artifacts due to the patient’s involuntary respiration during data acquisition and to improve the accuracy of bone perfusion assessment [25].
The use of ICG angiography was described also for perfusion assessment of scaphoid nonunions and it showed promising results to improve intraoperative decision-making [26]. ICG fluorescence imaging offers several advantages over conventional subjective intraoperative assessment methods. Firstly, it provides real-time visualization of tissue perfusion, allowing surgeons to accurately identify areas of compromised vascularity and necrotic bone. This capability is particularly crucial in cases of atrophic nonunion, where impaired blood supply can impede successful bone healing. By precisely delineating viable tissue, ICG angiography helps to guide the extent of debridement, ensuring thorough removal of necrotic material while preserving a healthy bone.
Secondly, ICG fluorescence imaging enhances intraoperative decision-making by providing objective, quantifiable data on tissue perfusion. Unlike subjective assessments based on visual cues such as tissue color and capillary refill, ICG angiography offers a standardized method for evaluating vascular integrity.
Furthermore, the safety profile of ICG makes it a viable option for routine use in orthopedic trauma surgery. Its low toxicity and minimal risk of adverse reactions ensure patient safety, while its short half-life and rapid excretion minimize the duration of exposure. This makes ICG angiography a practical and cost-effective intraoperative imaging modality, with the potential to improve outcomes and reduce healthcare costs associated with nonunion management.
Our paper opens new perspectives that can help surgeons in performing bone resections to preserve vital tissues where antibiotic and immune cells might be delivered. The use of ICG fluorescence imaging in surgery continues to evolve. Concerning nonunions treatment, it can assist surgeons in intraoperative decision-making to establish the resection levels avoiding massive bone defects.
While our study demonstrates promising results, several limitations warrant consideration. The sample size was small limiting the generalizability of our findings. Larger multicenter studies are needed to further validate the efficacy of ICG fluorescence imaging in nonunion management and to explore its applicability across different patient populations and clinical scenarios.
Conclusions
Our study highlights the potential of ICG fluorescence angiography as a valuable tool in the management of atrophic nonunion. By providing real-time assessment of tissue perfusion and guiding surgical decision-making, ICG imaging enhances the precision and effectiveness of reconstructive procedures, ultimately improving outcomes for patients with complex bone defects. Further research is warranted to validate these findings and optimize the integration of ICG angiography into routine orthopedic practice.
DISCLAIMERS
Acknowledgements. We extend our gratitude to Emanuela Morenghi, MA for her support in study design and statistical analysis.
Funding source. This study was not supported by any external sources of funding.
Disclosure competing interests. The authors declare that they have no competing interests.
Ethics approval. The study was approved by the Comitato Etico Territoriale Lombardia 5 (protocol N 1, 22.02.2024).
Consent for publication. The authors obtained written consent from patients to participate in the study and publish the results.
ДОПОЛНИТЕЛЬНАЯ ИНФОРМАЦИЯ
Благодарность. Мы выражаем благодарность Э. Моренги за помощь в разработке дизайна исследования и выполнении статистического анализа.
Источник финансирования. Авторы заявляют об отсутствии внешнего финансирования при проведении исследования.
Возможный конфликт интересов. Авторы декларируют отсутствие явных и потенциальных конфликтов интересов, связанных с публикацией настоящей статьи.
Этическая экспертиза. Исследование одобрено локальным этическим комитетом Ломбардии 5 (выписка из протокола № 1 от 22.02.2024).
Информированное согласие на публикацию. Авторы получили письменное согласие пациентов на участие в исследовании и публикацию результатов.
